Collection: A Section 2 Banded Belt Interchange Chart
A Section 2 Banded Belt
Banded A-Series Belts are engineered for high-load applications and reduced vibration, making them ideal for drives with multiple pulleys or where belt stability is essential. When replacing or specifying a belt, always match the exact dimensions required by your machinery or pulley system. Manufacturers offer detailed catalogs and specification sheets that outline available sizes, belt profiles, and material compositions—critical details to ensure proper fit, reliable operation, and maximum performance.
| Standard Belt # | Gates Belt # | Bando Belt # | Goodyear Belt # |
|---|---|---|---|
| 2/A43 | 2/A43 | 2A43 | A43/2 |
| 2/A44 | 2/A44 | 2A44 | A44/2 |
| 2/A45 | 2/A45 | 2A45 | A45/2 |
| 2/A46 | 2/A46 | 2A46 | A46/2 |
| 2/A47 | 2/A47 | 2A47 | A47/2 |
| 2/A48 | 2/A48 | 2A48 | A48/2 |
| 2/A49 | 2/A49 | 2A49 | A49/2 |
| 2/A50 | 2/A50 | 2A50 | A50/2 |
| 2/A51 | 2/A51 | 2A51 | A51/2 |
| 2/A52 | 2/A52 | 2A52 | A52/2 |
| 2/A53 | 2/A53 | 2A53 | A53/2 |
| 2/A54 | 2/A54 | 2A54 | A54/2 |
| 2/A55 | 2/A55 | 2A55 | A55/2 |
| 2/A56 | 2/A56 | 2A56 | A56/2 |
| 2/A57 | 2/A57 | 2A57 | A57/2 |
| 2/A58 | 2/A58 | 2A58 | A58/2 |
| 2/A59 | 2/A59 | 2A59 | A59/2 |
| 2/A60 | 2/A60 | 2A60 | A60/2 |
| 2/A61 | 2/A61 | 2A61 | A61/2 |
| 2/A62 | 2/A62 | 2A62 | A62/2 |
| 2/A63 | 2/A63 | 2A63 | A63/2 |
| 2/A64 | 2/A64 | 2A64 | A64/2 |
| 2/A65 | 2/A65 | 2A65 | A65/2 |
| 2/A66 | 2/A66 | 2A66 | A66/2 |
| 2/A67 | 2/A67 | 2A67 | A67/2 |
| 2/A68 | 2/A68 | 2A68 | A68/2 |
| 2/A69 | 2/A69 | 2A69 | A69/2 |
| 2/A70 | 2/A70 | 2A70 | A70/2 |
| 2/A71 | 2/A71 | 2A71 | A71/2 |
| 2/A72 | 2/A72 | 2A72 | A72/2 |
| 2/A73 | 2/A73 | 2A73 | A73/2 |
| 2/A74 | 2/A74 | 2A74 | A74/2 |
| 2/A75 | 2/A75 | 2A75 | A75/2 |
| 2/A76 | 2/A76 | 2A76 | A76/2 |
| 2/A77 | 2/A77 | 2A77 | A77/2 |
| 2/A78 | 2/A78 | 2A78 | A78/2 |
| 2/A79 | 2/A79 | 2A79 | A79/2 |
| 2/A80 | 2/A80 | 2A80 | A80/2 |
| 2/A81 | 2/A81 | 2A81 | A81/2 |
| 2/A82 | 2/A82 | 2A82 | A82/2 |
| 2/A83 | 2/A83 | 2A83 | A83/2 |
| 2/A84 | 2/A84 | 2A84 | A84/2 |
| 2/A85 | 2/A85 | 2A85 | A85/2 |
| 2/A86 | 2/A86 | 2A86 | A86/2 |
| 2/A87 | 2/A87 | 2A87 | A87/2 |
| 2/A88 | 2/A88 | 2A88 | A88/2 |
| 2/A89 | 2/A89 | 2A89 | A89/2 |
| 2/A90 | 2/A90 | 2A90 | A90/2 |
| 2/A91 | 2/A91 | 2A91 | A91/2 |
| 2/A92 | 2/A92 | 2A92 | A92/2 |
| 2/A93 | 2/A93 | 2A93 | A93/2 |
| 2/A94 | 2/A94 | 2A94 | A94/2 |
| 2/A95 | 2/A95 | 2A95 | A95/2 |
| 2/A96 | 2/A96 | 2A96 | A96/2 |
| 2/A97 | 2/A97 | 2A97 | A97/2 |
| 2/A98 | 2/A98 | 2A98 | A98/2 |
| 2/A99 | 2/A99 | 2A99 | A99/2 |
| 2/A100 | 2/A100 | 2A100 | A100/2 |
| 2/A101 | 2/A101 | 2A101 | A101/2 |
| 2/A102 | 2/A102 | 2A102 | A102/2 |
| 2/A103 | 2/A103 | 2A103 | A103/2 |
| 2/A104 | 2/A104 | 2A104 | A104/2 |
| 2/A105 | 2/A105 | 2A105 | A105/2 |
| 2/A106 | 2/A106 | 2A106 | A106/2 |
| 2/A107 | 2/A107 | 2A107 | A107/2 |
| 2/A108 | 2/A108 | 2A108 | A108/2 |
| 2/A109 | 2/A109 | 2A109 | A109/2 |
| 2/A110 | 2/A110 | 2A110 | A110/2 |
| 2/A111 | 2/A111 | 2A111 | A111/2 |
